LEGRAND RCD DX-ID – 4P 400 V~ neutral right hand side – 100 A – 300 mA – A type

Product Features:

• Robust 4-pole residual current device (RCD) from Schneider Electrics DX-ID range, designed for earth leakage protection in 400V~ three-phase electrical systems with right-hand side neutral configuration.
• Rated at 100A with Type A sensitivity capable of detecting both sinusoidal AC and pulsating DC residual currents, ideal for modern installations with electronic devices and appliances.
• 300mA leakage current sensitivity suited for fire protection and equipment safety, typically used as upstream protection without nuisance tripping in non-personnel protection areas.
• Ensures full disconnection of all active conductors, including neutral, in the event of a fault for maximum electrical safety.
• Right-hand neutral placement simplifies wiring in specific panel configurations and enhances flexibility during installation.
• DIN rail mountable for quick, safe integration into distribution boards and consumer units.
• Manual test button included for regular functional checks, ensuring continued device reliability and compliance.
• Complies with IEC/EN 61008-1 standards, providing international-grade safety, durability, and performance assurance.
